GE IS200STCIH6AED

IS200STCIH6AED 是一款用于 GE Mark VI 系列涡轮机控制系统的 DIN 导轨接触端子板。 IS200STCIH6AED 是一块印刷电路板 (PCB)，具有许多不同的组件。板子的左右两侧有两个镍大小的工厂钻孔。板子的左下角和右下角还有两个工厂钻好的加固端子孔。底部孔旁边有两个带有数字标记的端子板。顶部组标记为 1-51，仅包含奇数号码，而底部组标记为 2-52，包含所有偶数号码。板的顶部中心边缘有一个 RS-232 37 针母端口。该板的部件号标签位于板的右下侧，位于角落和大型工厂钻孔之间。板左侧顶部端子条上方有一个白色 3 针跳线。该 PCB 还包含 2 个晶体管、91 个电阻器、27 个二极管、 IS200STCIH6AED 是 PCB，应小心处理。应实施防静电程序，以防止由于静电的积聚和释放而对电路板造成任何类型的损坏。在安装之前，应将板保存在防静电袋或盒子中。安装IS200STCIH6AED时，应佩戴防静电腕带。为了帮助安装，建议记下要更换的旧板上的接线和电缆位置。

如果您需要咨询或购买，请将产品型号发送到我的邮箱或直接打电话给我。

The communication module of the programmable controller is equivalent to the network interface in the local area network. The communication module data bus is connected with the host of the programmable controller, and the communication protocol is realized by hardware and software together. The communication module of the programmable controller is generally equipped with several interfaces, which can be selected through the selection switch on the communication module to realize the communication with other programmable controllers, intelligent control devices or computers.

The input module is used to receive and collect the input signal. The input signal has two types: one is the switch input signal provided by the button switch, the stroke switch, the digital dip switch, the proximity switch, the photoelectric switch, the pressure relay, etc. The other is a continuously changing analog input signal sent by potentiometer, thermoelectric, tonometer motor, and various transmitters. The input module also needs to convert these different level signals into digital signals that the CPU can receive and process.

The function of the output module is to receive the digital signal processed by the central processor, and convert it into a signal that can be received by the field executive parts, which is used to control the contactor, solenoid valve, regulating valve, speed regulating device, etc. Another type of load control is the indicator light, digital display and alarm device.

离散输入模块

开关量输入模块从输入设备（如传感器、按钮和开关这些可以具有两种状态—开/关的装置）接收信号。模块需要一个底座（IC200CHSxxx）上 。

公司专注于DCS、PLC、机器人、大型伺服四大系统

主要产品有各种模块/卡、控制器、触摸屏、伺服驱动器 公司优势：供应进口原装产品，专业生产配件 保修一年，交货时间快，货源齐全！！！ ① 24小时邮件回复(12小时); ② 装运到亚洲以外的国家，请与卖方联系。
